Hoot and Holler over V3PN Configuration Example
Configure
4
OL-6573-01
Following are the callout terms and definitions for the diagram, identified by number:
The Headquarters location (callout 1) uses a Cisco 3845 router with these characteristics:
•
ATM access to the Internet
•
Operating in a Cisco CallManager cluster
•
Public IP address: 10.32.152.26
•
Private IP address pool: 192.168.1.0/24
The Branch 1 location (callout 8) uses a Cisco 2801 router with these characteristics:
•
DSL access to the Internet
•
WIC-SHDSL-V2 interface card installed
•
Public IP address: 10.32.153.32
•
Private IP address pool: 192.168.2.0/24
The Branch 2 location (callout 9) uses a Cisco 2811 router with these characteristics:
•
Serial access to the Internet
•
Public IP address: 10.32.150.46/30
•
Private IP address pool: 192.168.3.0/24
Configurations
This document uses the following configurations:
•
Headquarters Office Configuration (Cisco 3845 Router), page 4
•
Branch 1 Router Configuration (Cisco 2801 Router), page 9
•
Branch 2 Router Configuration (Cisco 2811 Router), page 14
Headquarters Office Configuration (Cisco 3845 Router)
HUB-R1# show running-config
Building configuration...
Current configuration : 9385 bytes
!
version 12.3
no service pad
service timestamps debug datetime msec
1 Headquarters location 6 DSL link from the Branch 1 router to the
Internet
2 ATM link from the Headquarters router to the
Internet
7 Serial link from the Branch 2 router to the
Internet
3 VPN tunnel through the Internet to Branch 1 8 Branch 1 location
4 The Internet, as represented by the cloud 9 Branch 2 location
5 VPN tunnel through the Internet to Branch 2
