Cisco 2800 Series User Manual

11
Using the ROM Monitor
OL-5997-02
How to Use the ROM Monitor—Typical Tasks
DETAILED STEPS
Examples
The following example shows how to load boot flash memory and USB boot flash memory:
rommon 7 > boot flash:[filename]
program load complete, entry point: 0x8000f000, size: 0xcb80
program load complete, entry point: 0x8000f000, size: 0xe2eb30
Self decompressing the image :
##########################################################################################
############################################################### [OK]
Smart Init is enabled
Smart init is sizing iomem
ID MEMORY_REQ TYPE
0003E9 0X003DA000 Router Mainboard
0X0014B430 DSP SIMM
0X000021B8 Onboard USB
0X002C29F0 public buffer pools
0X00211000 public particle pools
Command or Action Purpose
Step 1
boot
or
boot flash:[filename]
or
boot filename tftpserver
or
boot [filename]
or
boot usbflash[x]:[filename]
Example:
ROMMON > boot
Example:
ROMMON > boot flash:
Example:
ROMMON > boot someimage 172.16.30.40
Example:
ROMMON > boot someimage
Example:
ROMMON > boot usbflash0:someimage
In order, the examples here direct the router to:
• Boot the first image in flash memory.
• Boot the first image or a specified image in flash
memory.
• Boot the specified image over the network from the
specified TFTP server (hostname or IP address).
• Boot from the boothelper image because it does not
recognize the device ID. This form of the command is
used to boot a specified image from a network (TFTP)
server.
• Boot the image stored on the USB flash device.
Note Platforms can boot from USB in ROM monitor with
or without a compact flash device. It is not
necessary to use a bootloader image from the
compact flash device. Partitions, such as
usbflash0:2:image_name, are not supported on USB
flash drives. The boot usbflash<x>: command will
boot the first file on the device, if it is a valid image.
You can override the default boothelper image setting by
setting the BOOTLDR Monitor environment variable to
point to another image. Any system image can be used for
this purpose.
• Options for the boot command are -x (load image but
do not execute) and -v (verbose).

Cisco 2800 Series Specifications

General

Power Supply	Internal power supply
Product Type	Router
Form Factor	Rack-mountable
Connectivity Technology	Wired
Power Device	Internal power supply
Operating System	Cisco IOS
Integrated Services	Security, voice
WAN Interfaces	T1/E1, Serial
LAN Interfaces	Fast Ethernet, Gigabit Ethernet
Expansion Slots	4
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Network/Transport Protocol	IP, TCP
Remote Management Protocol	SNMP, Telnet
Features	VPN support, Quality of Service (QoS), VLAN support
Voltage Required	AC 100-240 V
Security Features	Firewall, VPN, Access Control Lists (ACLs)
