Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Network Configuration Menu
4-14
Cisco Unified IP Phone 7961G/7961G-GE and 7941G/7941G-GE for Cisco Unified Communications Manager 6.0
OL-11953-01
PC Port
Configuration
Speed and duplex of the access port (labeled
10/100 PC on the 7961G and 7941G; labeled
10/100/100 PC on the 7961G-GE and
7941G-GE). Valid values:
• Auto Negotiate
• 10 Half—10-BaseT/half duplex
• 10 Full—10-BaseT/full duplex
• 100 Half—100-BaseT/half duplex
• 100 Full—100-BaseT/full duplex
• 1000 Full—1000-BaseT/full duplex
If the phone is connected to a switch, configure
the port on the switch to the same speed/duplex
as the phone, or configure both to
auto-negotiate.
If you change the setting of this option, you
must change the SW Port Configuration option
to the same setting.
1. Unlock network
configuration options.
2. Scroll to the PC Port
Configuration option and
then press the Edit softkey.
3. Scroll to the setting that you
want and then press the
Select softkey.
4. Press the Save softkey.
PC VLAN Allows the phone to interoperate with
third-party switches that do not support a voice
VLAN.
The Admin VLAN ID option must be set before
using this option.
1. Unlock network
configuration options.
2. Make sure the Admin
VLAN ID is set (see Admin
VLAN ID above in this
table).
3. Scroll to the PC VLAN
option, press the Edit
softkey, and then enter a new
PC VLAN setting.
4. Press the Val idate softkey
and then press the Save
softkey.
Table 4-2 Network Configuration Menu Options (continued)
Option Description To Change
