7-13
Cisco Unified IP Phone 7961G/7961G-GE and 7941G/7941G-GE for Cisco Unified Communications Manager 6.0
OL-11953-01
Chapter 7 Viewing Model Information, Status, and Statistics on the Cisco Unified IP Phone
Status Menu
Network Statistics Screen
The Network Statistics screen displays information about the phone and network
performance. Table 7-3 describes the information that appears in this screen.
To display the Network Statistics screen, follow these steps:
Procedure
Step 1 Press the Settings button.
Step 2 Select Status.
Step 3 Select Status > Network Statistics.
To reset the Rx Frames, Tx Frames, and Rx Broadcasts statistics to 0, press the
Clear softkey.
To exit the Network Statistics screen, press the Exit softkey.
Version error The name of the phone load
file is incorrect.
Make sure that the phone load file has the
correct name.
XmlDefault.cnf.xml,
or .cnf.xml
corresponding to the
phone device name
Name of the configuration file. None. This is an informational message
indicating the name of the configuration file
for the phone.
Table 7-2 Status Messages on the Cisco Unified IP Phone (continued)
Message Description Possible Explanation and Action
Table 7-3 Network Statistics Message Information
Item Description
Rx Frames Number of packets received by the phone
Tx Frames Number of packets sent by the phone
Rx Broadcasts Number of broadcast packets received by the phone
