4-45
Cisco Unified IP Phone 7961G/7961G-GE and 7941G/7941G-GE for Cisco Unified Communications Manager 6.0
OL-11953-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Security Configuration Menu
CTL File Screen
The CTL File screen includes the options described in Table 4-16
If a CTL file is installed on the phone, you can access the CTL File menu by
pressing the Settings button and choosing Security Configuration > CTL File.
To exit the CTL File menu, press the Exit softkey.
CTL File Displays the MD5 hash of the
certificate trust list (CTL) file that is
installed in the phone, and provides
access to the CTL File menu. If no CTL
file is installed on the phone, this field
displays No. (If security is configured
for the phone, the CTL file installs
automatically when the phone reboots
or resets.
For more information about this file, refer
to the “Configuring the Cisco CTL
Client” chapter in Cisco Unified
Communications Manager Security
Guide.)
If a CTL file is installed on the phone,
also provides access to the CTL File
screen. For more information, see “CTL
File Screen” section on page 4-45.
Trust List If a CTL file is installed on the phone,
provides access to the Trust List menu.
For more information, see the “Trust List
Screen” section on page 4-47.
CAPF Server Displays the IP address and the port of
the CAPF that the phone uses.
For more information about this server,
refer to the “Using the Certificate
Authority Proxy Function” section in
Cisco Unified Communications Manager
Security Guide.
802.1X
Authentication
Allows you to enable 802.1X
authentication for this phone.
See the “802.1X Authentication and
Status” section on page 4-48.
802.1X
Authentication
Status
Displays real-time status progress of
the 802.1X authentication transaction.
Display only—Cannot configure.
Table 4-15 Security Menu Settings (continued)
Option Description To Change
