8-7
Cisco Unified IP Phone 7961G/7961G-GE and 7941G/7941G-GE for Cisco Unified Communications Manager 6.0
OL-11953-01
Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Network Configuration
Table 8-2 Network Configuration Area Items
Item Description
DHCP Server IP address of the Dynamic Host Configuration Protocol (DHCP) server from
which the phone obtains its IP address.
BOOTP Server Indicates whether the phone obtains its configuration from a Bootstrap
Protocol (BootP) server.
MAC Address Media Access Control (MAC) address of the phone.
Host Name Host name that the DHCP server assigned to the phone.
Domain Name Name of the Domain Name System (DNS) domain in which the phone
resides.
IP Address Internet Protocol (IP) address of the phone.
Subnet Mask Subnet mask used by the phone.
TFTP Server 1 Primary Trivial File Transfer Protocol (TFTP) server used by the phone.
Default Router 1–5 Default router used by the phone (Default Router 1) and optional backup
routers (Default Router 2–5).
DNS Server 1–5 Primary Domain Name System (DNS) server (DNS Server 1) and optional
backup DNS servers (DNS Server 2–5) used by the phone.
Operational VLAN ID Auxiliary Virtual Local Area Network (VLAN) configured on a Cisco
Catalyst switch in which the phone is a member.
Admin. VLAN ID Auxiliary VLAN in which the phone is a member.
