Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Streaming Statistics
8-16
Cisco Unified IP Phone 7961G/7961G-GE and 7941G/7941G-GE for Cisco Unified Communications Manager 6.0
OL-11953-01
Max MOS LQK Baseline or highest MOS LQK score observed from start of the voice stream.
These codecs provide the following maximum MOS LQK score under normal
conditions with no frame loss:
• G.711 gives 4.5
• G.729 A /AB gives 3.7
MOS LQK Version Version of the Cisco proprietary algorithm used to calculate MOS LQK
scores.
Cumulative Conceal
Ratio
Total number of concealment frames divided by total number of speech
frames received from start of the voice stream.
Interval Conceal Ratio Ratio of concealment frames to speech frames in preceding 3-second interval
of active speech. If using voice activity detection (VAD), a longer interval
might be required to accumulate 3 seconds of active speech.
Max Conceal Ratio Highest interval concealment ratio from start of the voice stream.
Conceal Secs Number of seconds that have concealment events (lost frames) from the start
of the voice stream (includes severely concealed seconds).
Severely Conceal Secs Number of seconds that have more than 5 percent concealment events (lost
frames) from the start of the voice stream.
Latency
1
Estimate of the network latency, expressed in milliseconds. Represents a
running average of the round-trip delay, measured when RTCP receiver report
blocks are received.
Max Jitter Maximum value of instantaneous jitter, in milliseconds.
Sender Size RTP packet size, in milliseconds, for the transmitted stream.
Sender Reports
Received
1
Number of times RTCP Sender Reports have been received.
Sender Report Time
Received
1
Last time at which an RTCP Sender Report was received.
Rcvr Size RTP packet size, in milliseconds, for the received stream.
Rcvr Discarded RTP packets received from network but discarded from jitter buffers.
Rcvr Reports
Received
1
Number of times RTCP Receiver Reports have been received.
Table 8-5 Streaming Statistics Area Items (continued)
Item Description
