Cisco 7961G-GE - IP Phone VoIP - Page 81

3-9
Cisco Unified IP Phone 7961G/7961G-GE and 7941G/7941G-GE for Cisco Unified Communications Manager 6.0
OL-11953-01
Chapter 3 Setting Up the Cisco Unified IP Phone
Installing the Cisco Unified IP Phone
Step 4
Connect a Category 3 or 5
straight-through Ethernet cable
from the switch to the network
port labeled 10/100 SW on the
Cisco Unified IP Phone
7961G/7941G, or to the network
port labeled 10/100/1000 SW on
the Cisco Unified IP Phone
7961G-GE/7941G-GE.
Each
Cisco Unified IP Phone
ships with one Ethernet
cable in the box.
See the “Network and
Access Ports” section on
page 3-4 for guidelines.
Step 5
Connect a Category 3 or 5
straight-through Ethernet cable
from another network device,
such as a desktop computer, to
the access port labeled 10/100
PC port on the
Cisco Unified IP Phone
7961G/7941G, or to the access
port labeled 10/100/1000 PC on
the Cisco Unified IP Phone
7961G-GE/7941G-GE.
Optional. You can connect
another network device later
if you do not connect one
now.
See the “Network and
Access Ports” section on
page 3-4 for guidelines.
Procedure Notes Reference
