Cisco 8800 Series Deployment Guide

Cisco IP Phone 8800 Series Wireless LAN Deployment Guide
13
48 Mbps
OFDM - 64 QAM
-78 dBm
54 Mbps
OFDM - 64 QAM
-76 dBm
5 GHz - 802.11n (HT20)
Data Rate
Modulation
Receiver Sensitivity
Max Tx Power = 13 dBm
(Depends on region)
7 Mbps (MCS 0)
OFDM - BPSK
-94 dBm
14 Mbps (MCS 1)
OFDM - QPSK
-91 dBm
21 Mbps (MCS 2)
OFDM - QPSK
-89 dBm
29 Mbps (MCS 3)
OFDM - 16 QAM
-86 dBm
43 Mbps (MCS 4)
OFDM - 16 QAM
-82 dBm
58 Mbps (MCS 5)
OFDM - 64 QAM
-77 dBm
65 Mbps (MCS 6)
OFDM - 64 QAM
-76 dBm
72 Mbps (MCS 7)
OFDM - 64 QAM
-74 dBm
5 GHz - 802.11n (HT40)
Data Rate
Modulation
Receiver Sensitivity
Max Tx Power = 13 dBm
(Depends on region)
15 Mbps (MCS 0)
OFDM - BPSK
-91 dBm
30 Mbps (MCS 1)
OFDM - QPSK
-88 dBm
45 Mbps (MCS 2)
OFDM - QPSK
-86 dBm
60 Mbps (MCS 3)
OFDM - 16 QAM
-83 dBm
90 Mbps (MCS 4)
OFDM - 16 QAM
-79 dBm
120 Mbps (MCS 5)
OFDM - 64 QAM
-75 dBm
135 Mbps (MCS 6)
OFDM - 64 QAM
-73 dBm
150 Mbps (MCS 7)
OFDM - 64 QAM
-72 dBm
5 GHz - 802.11ac (VHT20)
Data Rate
Modulation
Receiver Sensitivity
Max Tx Power = 12 dBm
(Depends on region)
7 Mbps (MCS 0)
OFDM - BPSK
-93 dBm
14 Mbps (MCS 1)
OFDM - QPSK
-90 dBm
21 Mbps (MCS 2)
OFDM - QPSK
-87 dBm
29 Mbps (MCS 3)
OFDM - 16 QAM
-84 dBm
43 Mbps (MCS 4)
OFDM - 16 QAM
-81 dBm
58 Mbps (MCS 5)
OFDM - 64 QAM
-76 dBm
65 Mbps (MCS 6)
OFDM - 64 QAM
-75 dBm
72 Mbps (MCS 7)
OFDM - 64 QAM
-74 dBm
87 Mbps (MCS 8)
OFDM – 256 QAM
-70 dBm
5 GHz - 802.11ac (VHT40)
Data Rate
Modulation
Receiver Sensitivity
Max Tx Power = 12 dBm
(Depends on region)
15 Mbps (MCS 0)
OFDM - BPSK
-90 dBm
30 Mbps (MCS 1)
OFDM - QPSK
-87 dBm
45 Mbps (MCS 2)
OFDM - QPSK
-85 dBm
60 Mbps (MCS 3)
OFDM - 16 QAM
-82 dBm
90 Mbps (MCS 4)
OFDM - 16 QAM
-79 dBm
120 Mbps (MCS 5)
OFDM - 64 QAM
-73 dBm
135 Mbps (MCS 6)
OFDM - 64 QAM
-72 dBm
150 Mbps (MCS 7)
OFDM - 64 QAM
-72dBm
180 Mbps (MCS 8)
OFDM – 256 QAM
-67 dBm
200 Mbps (MCS 9)
OFDM – 256 QAM
-66 dBm

Cisco 8800 Series Specifications

General

Protocols	SIP, SCCP
Audio	Wideband audio
Connectivity	Gigabit Ethernet
Power	Power over Ethernet (PoE)
Bluetooth	Yes
USB	Yes
Codec Support	G.711, G.722, G.729, iLBC
Dimensions	Varies by model
Weight	Varies by model
Wi-Fi	Yes (varies by model)
