Cisco 8800 Series Deployment Guide

Cisco IP Phone 8800 Series Wireless LAN Deployment Guide
14
2.4 GHz Specifications
2.4 GHz - 802.11b
Data Rate
Modulation
Receiver Sensitivity
Max Tx Power = 17 dBm
(Depends on region)
1 Mbps
DSSS - BPSK
-98 dBm
2 Mbps
DSSS - QPSK
-96 dBm
5.5 Mbps
DSSS - CCK
-93 dBm
11 Mbps
DSSS - CCK
-91 dBm
2.4 GHz - 802.11g
Data Rate
Modulation
Receiver Sensitivity
Max Tx Power = 14 dBm
(Depends on region)
6 Mbps
OFDM - BPSK
-95 dBm
9 Mbps
OFDM - BPSK
-94 dBm
12 Mbps
OFDM - QPSK
-93 dBm
18 Mbps
OFDM - QPSK
-90 dBm
24 Mbps
OFDM - 16 QAM
-87 dBm
36 Mbps
OFDM - 16 QAM
-84 dBm
48 Mbps
OFDM - 64 QAM
-79 dBm
54 Mbps
OFDM - 64 QAM
-77 dBm
2.4 GHz - 802.11n (HT20)
Data Rate
Modulation
Receiver Sensitivity
Max Tx Power = 13 dBm
(Depends on region)
7 Mbps (MCS 0)
OFDM - BPSK
-95 dBm
14 Mbps (MCS 1)
OFDM - QPSK
-92 dBm
21 Mbps (MCS 2)
OFDM - QPSK
-90 dBm
29 Mbps (MCS 3)
OFDM - 16 QAM
-87 dBm
43 Mbps (MCS 4)
OFDM - 16 QAM
-83 dBm
58 Mbps (MCS 5)
OFDM - 64 QAM
-78 dBm
65 Mbps (MCS 6)
OFDM - 64 QAM
-77 dBm
72 Mbps (MCS 7)
OFDM - 64 QAM
-75 dBm
Note: Receiver sensitivity is the minimum signal needed to decode a packet at a certain data rate.
The above values are pure radio specifications and do not account for the gain of the single integrated antenna.
5 GHz - 802.11ac (VHT80)
Data Rate
Modulation
Receiver Sensitivity
Max Tx Power = 12 dBm
(Depends on region)
33 Mbps (MCS 0)
OFDM - BPSK
-87 dBm
65 Mbps (MCS 1)
OFDM - QPSK
-83 dBm
98 Mbps (MCS 2)
OFDM - QPSK
-81 dBm
130 Mbps (MCS 3)
OFDM - 16 QAM
-78 dBm
195 Mbps (MCS 4)
OFDM - 16 QAM
-75 dBm
260 Mbps (MCS 5)
OFDM - 64 QAM
-73 dBm
293 Mbps (MCS 6)
OFDM - 64 QAM
-68 dBm
325 Mbps (MCS 7)
OFDM - 64 QAM
-68 dBm
390 Mbps (MCS 8)
OFDM – 256 QAM
-64 dBm
433 Mbps (MCS 9)
OFDM – 256 QAM
-62 dBm

Cisco 8800 Series Specifications

General

Protocols	SIP, SCCP
Audio	Wideband audio
Connectivity	Gigabit Ethernet
Power	Power over Ethernet (PoE)
Bluetooth	Yes
USB	Yes
Codec Support	G.711, G.722, G.729, iLBC
Dimensions	Varies by model
Weight	Varies by model
Wi-Fi	Yes (varies by model)
