Description and Default ValueParameter
Allows you to select Speed and duplex of the Computer (access) port.
• Auto
• 10 HALF
• 10 FULL
• 100 HALF
• 100 FULL
• 1000 FULL
Perform one of the following:
• In the phone configuration file with XML(cfg.xml), enter a string in this format:
<PC_Port_Config ua="na">AUTO</PC_Port_Config>
• In the phone web interface, select the speed for the port or select Auto to allow
the system to select the speed.
Default: Auto
PC Port Config
Enables or disables the PC port on the phone.
Perform one of the following:
• In the phone configuration file with XML(cfg.xml), enter a string in this format:
<PC_PORT_Enable ua="na">Yes</PC_PORT_Enable>
• In the phone web interface, set this field to Yes or No to enable or disable the PC
port on the phone.
Allowed values: Yes|No
Default: Yes
PC PORT Enable
Enables or disables PC Port mirroring on the phone. When set to Yes, you can see the
packets on the phone.
Perform one of the following:
• In the phone configuration file with XML(cfg.xml), enter a string in this format:
<Enable_PC_Port_Mirror ua="na">No</Enable_PC_Port_Mirror>
• In the phone web interface, set this field to Yes or No to enable or disable PC
port mirroring on the phone.
Allowed values: Yes|No
Default: No
Enable PC Port
Mirror
See System Log Parameters, on page 43.Syslog Server
See System Log Parameters, on page 43.Syslog identifier
Cisco IP Phone 8800 Series Multiplatform Phone Administration Guide for Release 11.3(1) and Later
163
Cisco IP Phone Configuration
Parameters for Optional Network Configuration
