Cisco ASR 1000 Series Installation And Configuration Guide

4-15
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation and Initial Configuration Guide
OL-13208-03
Chapter 4 Cisco ASR 1006 Router Overview and Installation
Installing the Cisco ASR 1006 Router in a Rack
Figure 4-9 Installing the Cisco ASR 1006 Router in a Four-Post Equipment Rack
When handling the chassis, always follow proper lifting practices, see Chassis-Lifting Guidelines, page
3-20.
Note Inner clearance (the width between the inner sides of the two posts or rails) must be at least 19 inches
(48.26cm). The height of the chassis is 10.45 inches (26.543 cm). Airflow through the chassis is from
front to back.
Note Make sure the rack is stabilized.
Step 1 (Optional) Install a shelf in the rack to support the Cisco ASR 1006 Router. If you are using a shelf then
raise the chassis to the level of the shelf. Let the bottom of the chassis rest on the brackets, but continue
to support the chassis.Using two people, lift the chassis into the rack using the side handles and grasping
underneath the power supply bays.
Step 2 Position the chassis until the rack-mounting flanges are flush against the mounting rails on the rack.
1 Four-post equipment rack rear rail 3 Cisco ASR1006 front rack-mount brackets
2 Cisco ASR1006 rear rack-mount brackets 4 Four-post equipment rack front rail
