Chapter 5 Cisco ASR 1004 Router Overview and Installation
Connecting Power to Cisco ASR 1004 Router
• Use a crossover cable to connect to an MDI port
• Use a straight-through cable to connect to an MDI-X port
Figure 5-15 Cisco ASR 1000 Series RP1 MGMT Ethernet Port Connector
Connecting Power to Cisco ASR 1004 Router
Warning
The covers are an integral part of the safety design of the product. Do not operate the unit without the
covers installed.
Statement 1077
Warning
When you install the unit, the ground connection must always be made first and disconnected last.
Statement 1046
Warning
Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Statement 1003
Warning
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
1 MGMT Ethernet port 2 Cable-management bracket and U feature
device
