Appendix A Cisco ASR 1000 Series Routers Specifications
Cisco ASR 1006 Router Specifications
Cisco ASR 1006 Router BITS Port Signals and Pinouts
Table A-4 lists the pinouts of the front panel Building Integrated Timing Supply (BITS) RJ45 port.
Cisco ASR 1006 Router Console Port Signals and Pinouts
Table A-5 lists the pinouts of the dual RJ-45 ports for the front panel console and auxiliary ports.
6 RX Data– In Receive Data
7,8 NC
Table A-3 RJ-45 Management Ethernet Port Pinouts (continued)
Pin Signal Direction Description
Ta b l e A-4 BITS RJ-45 Receptacle Pinouts for Cisco ASR 1006 Router
Pin Signal Direction Description
1 RX Ring Input Receive Ring
2 RX Input Receive (T1/E1)
3, 4 N/C
5 TX Ring Unused
6 TX Unused
7,8 N/C
Ta b l e A-5 Console Port Pinouts for Cisco ASR 1006 Router
Pin Signal Direction Description
1
RTS Out Request to Send (tied to pin 8, CTS)
2
DTR Out Data Terminal Ready (always On)
3
TXD Out Transmit Data
4
GND — Ring Indicator
5
GND —
6
RXD In Receive Data
7
DSR In Data Terminal Ready
8
CTS In Clear to Send (tied to pin 1, RTS)
