Cisco ASR 1000 Series Installation And Configuration Guide

5-21
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation and Initial Configuration Guide
OL-13208-03
Chapter 5 Cisco ASR 1004 Router Overview and Installation
Connecting Console and Auxiliary Port Cables
Connecting Console and Auxiliary Port Cables
The Cisco ASR 1004 Router has a DCE-mode console port for connecting a console terminal and a
DTE-mode auxiliary port for connecting a modem or other DCE device (such as another router) to your
chassis.
Figure 5-14 shows the CON and AUX ports on the Cisco ASR 1000 Series RP1 route processor
card.
.
Figure 5-14 Cisco ASR 1000 Series RP1—CON and AUX Ports
Note Both the console and the auxiliary ports are asynchronous serial ports; any devices connected to these
ports must be capable of asynchronous transmission. (Asynchronous is the most common type of serial
device; for example, most modems are asynchronous devices.)
The Cisco ASR 1004 Router uses RJ-45 ports for both the auxiliary port and the console port.
For console and auxiliary port pinouts for the RJ-45 connector, see Cisco ASR 1004 Router
Specifications, page A-5. Both ports are configured as asynchronous serial ports.
Step 1 Before connecting a terminal to the console port, configure the terminal to match the chassis console
port as follows: 9600 baud, 8 data bits, no parity, 1 stop bits (9600 8N1).
Step 2 After you establish normal router operation, you can disconnect the terminal.
Connecting the Ethernet Management Port Cable
When using the Fast Ethernet Management port in the default mode (speed-auto and duplex-auto) the
port operates in auto-MDI/MDI-X mode. The port automatically provides the correct signal connectivity
through the Auto-MDI/MDI-X feature. The port automatically senses a crossover or straight-through
cable and adapts to it.
However, when the Fast Ethernet Management port is configured to a fixed speed (10/100/1000 Mbps)
through command-line interface (CLI) commands, the port is forced to MDI mode.
When in a fixed-speed configuration and MDI mode:
MI
N
A
C
O
MA
J
ST
B
Y
A
CTV
S
TA
T
A
S
R
10
0
0-
RP
1
P
WR
C
RI
T
0
S
P
A
-
4
X
O
C
3
-
P
O
S
0
1
2
3
A
A/
L
C/
A
A
/L
C/
A
A
/L
S
P
A
-
4
XO
C
3
-
P
O
S
S
TATUS
0
1
2
3
C/
A
A
/L
C/
A
A
/
L
C/A
A/
L
C/A
A
/L
SP
A
-
4
X
O
C
3
-
P
O
S
S
T
AT
US
0
1
2
3
C/
A
A
/L
C/
A
A/
L
C/A
A
/
L
C
/
A
A
/L
B
I
T
S
C
O
N
A
UX
CA
RR
IER
LIN
K
M
G
M
T
E
T
H
E
R
N
E
T
D
I
S
K
H
D
U
S
B
D
F
0
1
280181
1 2
1 Console port - CON 2 Auxiliary port - AUX

Cisco ASR 1000 Series Specifications

General

Series	ASR 1000
Category	Network Router
Operating System	Cisco IOS XE
Memory	Up to 64 GB
Interfaces	10 Gigabit Ethernet
Power Supply	AC or DC options
Dimensions	Varies by model
Encryption	IPsec, SSL
Storage	Varies by model
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	5% to 95% non-condensing
MTBF	Varies by model
