Cisco ASR 1000 Series Installation And Configuration Guide

A-11
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation and Initial Configuration Guide
OL-13208-03
Appendix A Cisco ASR 1000 Series Routers Specifications
Cisco ASR 1002 Router Specifications
Cisco ASR 1002 Router Auxiliary Port Signals and Pinouts
Table A-6 lists the pinouts of the dual RJ-45 ports for the auxiliary port signals.
Cisco ASR 1002 Router BITS Port Signals and Pinouts
Table A-20 lists the pinouts of the front panel Building Integrated Timing Supply (BITS) RJ45 port.
Ta b l e A-19 Auxiliary Port Pinouts for Cisco ASR 1002 Router
Pin Signal Direction Description
1
RTS Output Request to Send
2
DTR Output Data Terminal Ready (always On)
3
TXD Output Transmit Data
4
RI — Ring Indicator
5
GND —
6
RXD Input Receive Data
7
DSR/DCD Input Data Set Ready/Data Carrier Detect
8
CTS Input Clear to Send
Ta b l e A-20 BITS RJ-45 Interface Pinouts for Cisco ASR 1002 Router
Pin Signal Direction Description
1 RX Ring Input Receive Ring
2 RX TIP Input Receive TIP (T1/E1)
3, 4 N/C
5 TX Ring Unused
6 TX TIP Unused
7,8 N/C
