Cisco ASR 1000 Series Installation And Configuration Guide

A-9
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation and Initial Configuration Guide
OL-13208-03
Appendix A Cisco ASR 1000 Series Routers Specifications
Cisco ASR 1002 Router Specifications
Cisco ASR 1002 Router Memory and Storage Options
Table A-16 lists the hardware memory and storage options supported on the Cisco ASR 1002 Router.
Cisco ASR 1002 Router Ethernet RJ-45 Port Pinouts
The Cisco ASR 1002 Router has RJ-45 port for the 10/100/1000 Ethernet connections. The RJ-45 port
supports IEEE
802.3ab (Gigabit Ethernet) and IEEE 802.3u (Fast Ethernet) interfaces compliant with
10BASET, 100BASETX, and 1000BASET specifications.
The RJ-45 port supports standard straight-through and crossover Category 5 UTP cables with RJ-45
connectors. Cisco does not supply Category 5 UTP cables; these cables are available commercially.
Storage temperature • –38° to 150° F
• –40° to 70° C
Power consumption • Maximum DC: 590W
• Maximum AC: 560W
• Maximum (Out): 470W
Table A-15 Cisco ASR 1002 Router Specifications (continued)
Description Specification
Ta b l e A-16 Memory and Storage Options for Cisco ASR 1002 Router
Memory Type Default Maximum System Support
RP 1– DRAM 4 GB 4 GB – Not Field Upgradeable
FECP – DRAM 1GB for ASR1000-ESP-5
2GB for ASR1000-ESP10
2 GB – Not Field Upgradeable
eUSB – Internal Flash + NVRAM 8 GB on the built-in RP1 on the
Cisco ASR 1002 Router
(partitioned: 1 GB for
bootflash; 7 GB for mass
storage)
8 GB – Not Field Upgradeable
