Chapter 6 Cisco ASR 1002 Router Overview and Installation
General Rack Installation Guidelines
Note The Cisco ASR 1002 Router usually ships fully loaded. However, you can remove components from the
chassis to make the chassis lighter for your rack installation, such as the power supplies.
Warning This warning symbol means danger. You are in a situation that could cause bodily injury. Before you
work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar
with standard practices for preventing accidents. Use the statement number provided at the end of
each warning to locate its translation in the translated safety warnings that accompanied this device.
Statement 1071
Warning Before you install, operate, or service the system, read the Regulatory Compliance and Safety
Information for Cisco ASR 1000 Series Aggregation Services Routers publication. This document
provides important safety information you should know before working with the system. Statement 200
Note You have already unpacked your chassis and read all the site requirements for your new equipment.
Proceed with the installation.
General Rack Installation Guidelines
When planning your rack installation, consider the following guidelines:
• The Cisco ASR 1002 Router requires a minimum of 3.5 inches or 8.9 cm rack units of vertical rack
space. Measure the proposed rack location before mounting the chassis in the rack.
• Before using a particular rack, check for obstructions (such as a power strip) that could impair
rack-mount installation. If a power strip does impair a rack-mount installation, remove the power
strip before installing the chassis, and then replace it after the chassis is installed.
• Allow sufficient clearance around the rack for maintenance. If the rack is mobile, you can push it
back near a wall or cabinet for normal operation and pull it out for maintenance (installing or moving
cards, connecting cables, or replacing or upgrading components). Otherwise, allow 19 inches (48.3
cm) of clearance to remove field-replaceable units.
• Maintain a minimum clearance of 3 inches on the front and back sides of the chassis for the cooling
air inlet and exhaust ports, respectively. Avoid placing the chassis in an overly congested rack or
directly next to another equipment rack; otherwise, the heated exhaust air from other equipment can
enter the inlet air vents and cause an overtemperature condition inside the router.
Caution To prevent chassis overheating, never install a Cisco ASR 1002 Router in an enclosed room that is not
properly ventilated or air conditioned.
• Always install heavier equipment in the lower half of a rack to maintain a low center of gravity to
prevent the rack from falling over.
• Install and use the cable-management brackets included with the Cisco ASR 1002 Router to keep
cables organized and out of the way of the cards and processors. Ensure that cables from other
equipment already installed in the rack do not impair access to the cards or require you to disconnect
cables unnecessarily to perform equipment maintenance or upgrades.

Cisco ASR 1000 Series Specifications

General

Series	ASR 1000
Category	Network Router
Operating System	Cisco IOS XE
Memory	Up to 64 GB
Interfaces	10 Gigabit Ethernet
Power Supply	AC or DC options
Dimensions	Varies by model
Encryption	IPsec, SSL
Storage	Varies by model
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	5% to 95% non-condensing
MTBF	Varies by model
