Cisco ASR 1000 Series Installation And Configuration Guide

A-6
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation and Initial Configuration Guide
OL-13208-03
Appendix A Cisco ASR 1000 Series Routers Specifications
Cisco ASR 1004 Router Specifications
The RJ-45 port supports standard straight-through and crossover Category 5 UTP cables with RJ-45
connectors. Cisco does not supply Category 5 UTP cables; these cables are available commercially. See
Figure A-1 to see an RJ-45 port and connector.
Cisco ASR 1004 Router MGMT Ethernet Port Signals and Pinouts
Table A-3 lists the RJ-45 port pinout for the front panel Management Ethernet port.
Cisco ASR 1004 Router Console Port Signals and Pinouts
Table A-11 lists the pinouts of the dual RJ-45 ports for the front panel console and auxiliary ports.
Ta b l e A-10 RJ-45 Management Ethernet Port Pinouts for the Cisco ASR 1004 Router
Pin Signal Direction Description
1 TX Data+ Output Transmit Data
2 TX Data– Output Transmit Data
3 RX Data+ Input Receive Data
4, 5 NC
6 RX Data– Input Receive Data
7,8 NC
Ta b l e A-11 Console Port Pinouts for Cisco ASR 1004 Router
Pin Signal Direction Description
1
RTS Output Request to Send (tied directly to CTS)
2
DTR Output Data Terminal Ready (always On)
3
TXD Output Transmit Data
4
GND — Ring Indicator
5
GND —
6
RXD Input Receive Data
7
DSR Input Unused
8
CTS Input Clear to Send (tied to RTS)
