Appendix A Cisco ASR 1000 Series Routers Specifications
Cisco ASR 1002 Router Specifications
Cisco ASR 1004 Router DB-25 Pinout Assignments for Alarm Relays
Table A-14 lists the common, normally open, and normally closed relay contacts accessible to an
external alarm monitoring facility by means of the DB-25 connector.
For more information about the DB-25 alarm connector, seeCisco ASR 1006 Router DB-25 Pinout
Assignments for Alarm Relays, page A-4.
Cisco ASR 1002 Router Specifications
This section lists the specifications for the Cisco ASR 1002 Router.
Table A-15 lists the Cisco ASR 1002 Router physical specifications.
Ta b l e A-14 Cisco ASR 1004 Router DB-25 Alarm Connector Pinout Assignments
Signal Description
Common
(CM)
Normally
Open (NO)
Normally
Closed (NC)
SPARE
CRTAA Critical Audible Alarm 2 1 14
MAJAA Major Audible Alarm 16 3 15
MINAA Minor Audible Alarm 5 4 17
CRTVA Critical Visual Alarm 19 6 18
MAJVA
Major Visual Alarm
8 7 20
MINVA
Minor Visual Alarm
22 9 21
SPARE SPARE—unused pin
reserved for future use
10, 11, 12, 13,
23, 24, 25
Ta b l e A-15 Cisco ASR 1002 Router Specifications
Description Specification
Midplane Connects the Cisco embedded ASR1000-RP1, ASR 1000 ESP5 or ESP10, SPAs, and
power supplies together in the system
Dimensions (H x W x D) Height: 3.5 in. (8.9 cm)
Width: 17.25 in. (19-inch rack-mount or optional 23 Telco adaptor brackets)
Depth: 22.50 in. (including card handles, cable-management brackets, and power supply
handles) for mounting in a 600mm-enclosed cabinet
Weight 40 pounds (fully configured)
18.143 k
Nominal operating temperature • 41° to 104° F
• 5° to 40° C
Nominal operating humidity 10% to 85%
