Chapter 6 Cisco ASR 1002 Router Overview and Installation
Connecting Power to Cisco ASR 1002 Router
Figure 6-21 Positioning Cisco ASR 1002 Router AC Power Supply and Cord in Slot 1
b. Take the power cord and run it below the handles of the right and left power supplies. Make sure the
power cord is hanging loose so that it will not be disconnected from the AC power inlet as shown in
Figure 6-22.
Figure 6-22 Cisco ASR 1002 Router AC Power Supply in Slot 0 and Slot 1 With Power Cord
1 AC power cord
