Cisco ASR 9000 Serie

PurposeCommand or Action
(Optional) Enables the monitoring of a VPN (using a
nondefault routing table) in a UDP jitter operation. Maximum
length is 32 alphanumeric characters.
vrf vrf-name
Example:
RP/0/RSP0/CPU0:router(config-ipsla-udp-jitter)#
vrf VPN-A
Step 4
Specifies the IP address of the destination for the proper
operation type.
destination address ipv4address
Example:
RP/0/RSP0/CPU0:router(config-ipsla-udp-jitter)#
destination address 12.25.26.10
Step 5
Specifies the destination port number, in the range from 1 to
65535.
destination port port
Example:
RP/0/RSP0/CPU0:router(config-ipsla-udp-jitter)#
destination port 11111
Step 6
(Optional) Sets the rate at which a specified IP SLA operation
is sent into the network.
frequency seconds
Example:
RP/0/RSP0/CPU0:router(config-ipsla-udp-jitter)#
frequency 300
Step 7
•
(Optional) Use the seconds argument to specify the
number of seconds between the IP SLA operations. Valid
values are in the range from 1 to 12604800 seconds. The
default is 60 seconds.
(Optional) Specifies the statistics collection parameters for
UDP jitter operation.
statistics [hourly | interval seconds]
Example:
RP/0/RSP0/CPU0:router(config-ipsla-udp-jitter)#
Step 8
statistics hourly
RP/0/RSP0/CPU0:router(config-ipsla-op-stats)#
(Optional) Sets the number of hours in which statistics are
maintained for the IP SLA operations. This command is valid
buckets hours
Example:
RP/0/RSP0/CPU0:router(config-ipsla-op-stats)#
buckets 10
Step 9
only with the statistics command with hourly keyword. The
range is 0 to 25 hours. The default value is 2 hours.
(Optional) Sets the number of statistic distributions that are
kept for each hop during the lifetime of the IP SLA operation.
The range is 1 to 20. The default value is 1 distribution.
distribution count slot
Example:
RP/0/RSP0/CPU0:router(config-ipsla-op-stats)#
distribution count 15
Step 10
Cisco ASR 9000 Series Aggregation Services Router System Monitoring Configuration Guide, Release 4.2.x
216
Implementing IP Service Level Agreements
Configuring IP Service Levels Using the UDP Jitter Operation
