Prerequisites for Configuring a UDP Jitter Operation on the Source Device
Use of the UDP jitter operation requires that the IP SLA Responder be enabled on the target Cisco device.
To enable the IP SLA Responder, perform the task in the Enabling the IP SLA Responder on the Destination
Device, on page 209 section.
Configuring and Scheduling a Basic UDP Jitter Operation on the Source Device
You can configure and schedule a UDP jitter operation.
SUMMARY STEPS
1.
configure
2.
ipsla operation operation-number
3.
type udp jitter
4.
destination address ipv4address
5.
destination port port
6.
packet count count
7.
packet interval interval
8.
frequency seconds
9.
exit
10.
ipsla schedule operation op-num
11.
life { forever | seconds}
12.
ageout seconds
13.
recurring
14.
start-time [hh:mm:ss {day | month day} | now | pending | after hh:mm:ss]
15.
commit
DETAILED STEPS
PurposeCommand or Action
configure
Step 1
Specifies the operation number. The range is from 1 to 2048.
ipsla operation operation-number
Example:
RP/0/RSP0/CPU0:router(config)# ipsla operation
432
Step 2
Configures the operation as a UDP jitter operation, and
configures characteristics for the operation.
type udp jitter
Example:
RP/0/RSP0/CPU0:router(config-ipsla-op)# type
udp jitter
Step 3
Cisco ASR 9000 Series Aggregation Services Router System Monitoring Configuration Guide, Release 4.2.x
212
Implementing IP Service Level Agreements
Configuring IP Service Levels Using the UDP Jitter Operation
