Cisco ASR 9000 Serie

SUMMARY STEPS
1.
configure
2.
ipsla operation operation-number
3.
type udp echo
4.
destination address ipv4address
5.
destination port port
6.
frequency seconds
7.
exit
8.
ipsla schedule operation op-num
9.
life [forever | seconds]
10.
ageout seconds
11.
recurring
12.
start-time [hh:mm:ss {day | month day} | now | pending | after hh:mm:ss ]
13.
commit
14.
show ipsla statistics [operation-number]
15.
show ipsla statistics aggregated [operation-number]
DETAILED STEPS
PurposeCommand or Action
configure
Step 1
Specifies the operation number. The range is from 1 to 2048.
ipsla operation operation-number
Example:
RP/0/RSP0/CPU0:router(config)# ipsla operation
432
Step 2
Configures the operation as a UDP echo operation, and
configures characteristics for the operation.
type udp echo
Example:
RP/0/RSP0/CPU0:router(config-ipsla-op)# type
udp echo
Step 3
Specifies the IP address of the destination for the proper
operation type.You can configure a permanent port on the
IP SLA Responder side, or you can use an UDP echo server.
destination address ipv4address
Example:
RP/0/RSP0/CPU0:router(config-ipsla-udp-echo)#
destination address 12.25.26.10
Step 4
Specifies the destination port number, in the range from 1 to
65535.
destination port port
Example:
RP/0/RSP0/CPU0:router(config-ipsla-udp-echo)#
destination port 11111
Step 5
Cisco ASR 9000 Series Aggregation Services Router System Monitoring Configuration Guide, Release 4.2.x
220
Implementing IP Service Level Agreements
Configuring the IP SLA for a UDP Echo Operation
