Cisco ASR 9000 Serie

PurposeCommand or Action
Specifies the IP address of the destination for the proper
operation type.
destination address ipv4address
Example:
RP/0/RSP0/CPU0:router(config-ipsla-udp-echo)#
destination address 12.25.26.10
Step 5
Specifies the destination port number, in the range from 1 to
65535.
destination port port
Example:
RP/0/RSP0/CPU0:router(config-ipsla-udp-echo)#
destination port 11111
Step 6
(Optional) Sets the rate at which a specified IP SLA operation
is sent into the network.
frequency seconds
Example:
RP/0/RSP0/CPU0:router(config-ipsla-udp-echo)#
frequency 300
Step 7
•
(Optional) Use the seconds argument to specify the number
of seconds between the IP SLA operations. Valid values
are in the range from 1 to 12604800 seconds. The default
is 60 seconds.
(Optional) Sets the protocol data size in the payload of the IP
SLA operation's request packet.
datasize request size
Example:
RP/0/RSP0/CPU0:router(config-ipsla-udp-echo)#
datasize request 512
Step 8
•
Use the size argument to specify the protocol data size in
bytes. The range is from 0 to the maximum of the protocol.
The default is 1 byte.
Defines a type of service (ToS) byte in the IP header of IP SLA
operations.
tos number
Example:
RP/0/RSP0/CPU0:router(config-ipsla-udp-echo)#
tos 255
Step 9
The ToS byte is converted to a Differentiated Services
Code Point (DSCP) value, but you cannot enter the
DSCP value directly. To use a DSCP value, multiply
it by 4 and enter the result as the value of the number
argument.
Note
Sets the time that the specified IP SLA operation waits for a
response from its request packet.
timeout milliseconds
Example:
RP/0/RSP0/CPU0:router(config-ipsla-udp-echo)#
timeout 10000
Step 10
•
Use the milliseconds argument to specify the number of
milliseconds that the operation waits to receive a response.
(Optional) Creates a user-specified identifier for an IP SLA
operation.
tag text
Example:
RP/0/RSP0/CPU0:router(config-ipsla-udp-echo)#
type udp echo tag ipsla
Step 11
Cisco ASR 9000 Series Aggregation Services Router System Monitoring Configuration Guide, Release 4.2.x
224
Implementing IP Service Level Agreements
Configuring the IP SLA for a UDP Echo Operation
