Configuring MPLS Layer 2 VPNs
Configuring Frame Relay DLCI-to-ATM AAL5SNAP Bridged Interworking
13
Cisco ASR 1000 Series Aggregation Services Routers Software Configuration Guide
DETAILED STEPS
Command or Action Purpose
Step 1
enable
Example:
Router> enable
Enables the privileged EXEC mode.
Enter your password, if prompted.
Step 2
configure terminal
Example:
Router# configure terminal
Enters the global configuration mode.
Step 3
ipv6 unicast-routing
Example:
Router# ipv6 unicast-routing
(Optional) Enables the task of forwarding the IPv6
unicast datagrams.
Step 4
mpls label protocol ldp
Example:
Router(config)# mpls label protocol ldp
Specifies the label distribution protocol (LDP) for
the Frame Relay PE router.
Step 5
mpls ip default-route
Example:
Router(config)# mpls ip default-route
Enables the distribution of labels associated with the
IP default route.
Step 6
mpls ldp graceful-restart
Example:
Router(config)# mpls ldp graceful-restart
Enables MPLS LDP graceful restart.
Step 7
frame-relay switching
Example:
Router(config)# frame-relay switching
Enables PVC switching on a Frame Relay data
circuit-terminating equipment (DCE) device.
Step 8
xconnect logging pseudowire status
Example:
Router(config)# xconnect logging pseudowire status
Enables system logging (syslog) reporting of
pseudowire status events.
Step 9
controller t1 slot/subslot/port
Example:
Router(config)# controller T1 0/3/0
Configures a T1 controller and enters the controller
configuration mode.
Step 10
framing esf
Example:
Router(config-controller)# framing esf
Selects the Extended Super Frame (ESF) for a T1
data line.
