Table 155: MOIP, MOIP1, or MOIP2 Next level names (after Port Name)
DescriptionMOIP, MOIP1, or MOIP2 Next Level
Name
Output Mode
Type: String
Values: "No Output", "Passthrough", "Service Channels Only", "Map
Passthrough", "Map Service Channels Only", "Transcoding"
mode
Output Descrambling Mode
Type: String
Values: "Descrambled", "Scrambled"
dscrmode
Output Rate Control Mode
Type: String
Value: "User"
ratemode
Output Rate
Type: Float
Values: 0.0 ….. 206.0
rate
Insert Null Packet
Type: String
Values: "Yes", "No"
insertnul="No" is not allowed with ratemode="User"
insertnul
Set valid SAP destination IP address (multicast only)
Type: String
Value: IP address in dot format, for example, 224.2.127.254
mcastip
Set the SAP UDP destination port number
Type: Integer
Value: 1024..65534
destport
FEC arrangement : Block-aligned (0) or Non Block-aligned
Type: String
Values: "Block Aligned", "Non-Block Aligned"
fecscheme
Set the number of transport packets to be sent per IP packet
Type: Integer
Value: 1..7
tpperframe
Cisco D9800 Network Transport Receiver Version 2.75 RESTful Web Services API Reference Guide
179
API Definitions
Output Configuration Command
