IP Diagnostics Operation Status Command
Table 234: Command Details
DescriptionCommand Detail
https://192.168.0.1/ws/v1/table?t=IPDIAGSTATCommand URL
Return information about IP Diagnostics Status.Command Information
GETHTTP Method
ReadAccess Type
User, AdminAccess Level
GET "https://192.168.0.1/ws/v1/table?t=IPDIAGSTAT"GET Syntax
Example (issue the IP DIAG Status command):
Input:
curl -k -H "X-SESSION-ID: $token" "https://192.168.0.1/ws/v1/table?t=IPDIAGSTAT"
Expected output (example when diagnostics package preparation is in progress):
<?xml version="1.0" encoding="ISO-8859-1"
?><HDR><TABLE><RECORD><ITEM><ID>0x002D2600</ID><VALUE><![CDATA[Inprogress]]></VALUE><NAME>
<![CDATA[OPERSTATUS]]></NAME><HELP_STR_1><![CDATA[Indicates whether the most recent
operation passed, failed, or is in progress]]>
</HELP_STR_1><HELP_STR_2><![CDATA[This item has 3 options available.]]></HELP_STR_2>
</ITEM><ITEM><ID>0x002D2601</ID><VALUE><![CDATA[Processing]]></VALUE><NAME><![CDATA[DETAILEDSTATUS]]>
</NAME><HELP_STR_1><![CDATA[State of the current Ping Traceroute collection
operation]]></HELP_STR_1>
<HELP_STR_2><![CDATA[This item has 6 options
available.]]></HELP_STR_2></ITEM><ITEM><ID>0x002D2602</ID>
<VALUE><![CDATA[23]]></VALUE><NAME><![CDATA[PERCENTCOMPLETE]]></NAME><HELP_STR_1>
<![CDATA[Progress of the current Ping Traceroute Collection operation as a percent]]>
</HELP_STR_1><HELP_STR_2><![CDATA[Item attribute: min(0), max(100), step size(1), unit()]]>
</HELP_STR_2></ITEM></RECORD></TABLE></HDR>
Expected output (example when diagnostics package preparation is 100% completed successfully):
<?xml version="1.0" encoding="ISO-8859-1"
?><HDR><TABLE><RECORD><ITEM><ID>0x002D2600</ID><VALUE><![CDATA[Pass]]></VALUE><NAME>
<![CDATA[OPERSTATUS]]></NAME><HELP_STR_1><![CDATA[Indicates whether the most recent operation
passed, failed, or is in progress]]></HELP_STR_1><HELP_STR_2><![CDATA[This item has 3 options
available.]]></HELP_STR_2></ITEM><ITEM><ID>0x002D2601</ID><VALUE><![CDATA[Done]]></VALUE>
<NAME><![CDATA[DETAILEDSTATUS]]></NAME><HELP_STR_1><![CDATA[State of the current
Ping Traceroute collection operation]]></HELP_STR_1><HELP_STR_2><![CDATA[This item has 6
options
available.]]></HELP_STR_2></ITEM><ITEM><ID>0x002D2602</ID><VALUE><![CDATA[100]]></VALUE>
<NAME><![CDATA[PERCENTCOMPLETE]]></NAME><HELP_STR_1><![CDATA[Progress of the current Ping
Traceroute Collection operation as a percent]]></HELP_STR_1><HELP_STR_2>
<![CDATA[Item attribute: min(0), max(100), step size(1), unit()]]></HELP_STR_2>
</ITEM></RECORD></TABLE></HDR>
Expected output (example when ip diagnostics operation did not succeed):
<?xml version="1.0" encoding="ISO-8859-1"
?><HDR><TABLE><RECORD><ITEM><ID>0x002D2600</ID><VALUE><![CDATA[Fail]]></VALUE>
<NAME><![CDATA[OPERSTATUS]]></NAME><HELP_STR_1><![CDATA[Indicates whether the most recent
Cisco D9800 Network Transport Receiver Version 2.75 RESTful Web Services API Reference Guide
280
API Definitions
IP Diagnostics Commands
