DescriptionCommand Detail
Single-stream NTC MOIP or NTC Basic unit:
GET "https://192.168.0.1/ws/v2/service_cfg/output/asi/pe"
GET "https://192.168.0.1/ws/v2/service_cfg/output/asi2/pe"
Single-stream NTC MOIP unit:
GET "https://192.168.0.1/ws/v2/service_cfg/output/moip/pe"
GET "https://192.168.0.1/ws/v2/service_cfg/output/moip1/pe"
Multi-stream unit:
GET "https://192.168.0.1/ws/v2/service_cfg/output/asi1/pe"
GET "https://192.168.0.1/ws/v2/service_cfg/output/asi2/pe?mode"
GET "https://192.168.0.1/ws/v2/service_cfg/output/moip1/pe"
GET "https://192.168.0.1/ws/v2/service_cfg/output/moip2/pe?mode
GET Syntax
Single-stream unit:
POST "https://192.168.0.1/ws/v2/service_cfg/output/asi/pe?
peid=[peid#]&mode=<mode>... "
POST "https://192.168.0.1/ws/v2/service_cfg/output/moip/pe?
peid=[peid#]&mode=<mode>... "
Multi-stream unit:
POST "https://192.168.0.1/ws/v2/service_cfg/output/asi1/pe?
peid=[peid#]&mode=<mode>... "
POST "https://192.168.0.1/ws/v2/service_cfg/output/moip1/pe?
peid=[peid#]&mode=<mode>... "
POST Syntax
Setting Parameters using
command line arguments is
limited to maximum of 26
arguments after the ?.
URI Parameters (extension to the Command URL separated by /): N/A
All of the URI Arguments below apply to both GET and POST. For GET, the URI arguments do not
need any values, except the peid argument which must be supplied with a program entry ID value.
For POST any of the below URI arguments can be supplied with their associated value the user would
like to set.
Note
Table 164: URI Query/Set Arguments (possible fields and values preceded by ? and separated by &)
DescriptionURI Argument
Program Entry Identifier
Type: String
XML/JSON Format Value: PE1…PE32, P1A…P16A
Command Line Input Value: 1…32 (multi-stream), 1..16
(single-stream)
peid (Key)
Cisco D9800 Network Transport Receiver Version 2.75 RESTful Web Services API Reference Guide
194
API Definitions
Output Configuration Command
