Port DescriptionNTC Board
Five Ethernet ports:
•
Management
•
DATA1 and DATA2 (first data port pairs)
•
DATA3 and DATA4 (second data port pairs)
NTC-MS
When using "port" as a URI argument for web services API commands, the ports are referred to as port 0,
port 1, port 2, and so on.
"Management port" is port 0. This can be used on all three types of NTC boards.
DATA1 is port 1. This can be used on NTC MOIP and NTC-MS boards.
DATA2 is port 2. This can be used on NTC MOIP and NTC-MS boards.
DATA3 and DATA4 is port 3 and port 4 respectively. They can only be used on the NTC-MS board.
When connecting to a unit to run web services API commands, the Management port (port 0) is used to
establish and maintain the connection.
Note
The ports are labeled on the backplane of an assembled unit. The Management port (port 0) is labeled
Management. The DATA ports are labeled DATA1, DATA2, DATA3, and DATA4.
The Management port is also referred to as "Control port" in this document.Note
Cisco D9800 Network Transport Receiver Version 2.75 RESTful Web Services API Reference Guide
9
Web Services API
Port Information
