DescriptionCommand Detail
Singlestream unit:
POST "https://192.168.0.1/ws/v2/service_cfg/output/moip/ipo?
ipoid=[Stream#]&iporate=<ipo rate>... "
Multistream unit:
POST "https://192.168.0.1/ws/v2/service_cfg/output/moip1/ipo?
ipoid=[Stream#]&iporate=<ipo rate>... "
POST "https://192.168.0.1/ws/v2/service_cfg/output/moip2/ipo?
ipoid=[Stream#]&iporate=<ipo rate>... "
POST Syntax
Setting Parameters using
command line arguments is
limited to maximum of 26
arguments after the ?.
URI Parameters (extension to the Command URL separated by /): N/A
All of the URI Arguments below apply to both GET and POST. For GET, the URI arguments do not
need any values, except the peid argument which must be supplied with a program entry ID value.
For POST, any of the below URI arguments can be supplied with their associated value the user
would like to set.
Note
Table 166: URI Query/Set Arguments (possible fields and values preceded by ? and separated by &)
DescriptionURI Argument
Program Entry Identifier
Type: Integer
Values: 1…40 for D9800-MS with 8 Transcoders, 1…48 for MS with 16
Transcoders, 1..16 for D9800-SS
ipoid
Bitrate (in Mbps) of Transport output stream
Type: Float
Values: 0.0…800.0
iporate
Encapsulation of Transport output stream
Type: String
Values: "RTP", "UDP"
encaps
Destination IP Address
Type: String
Values: IP address in the dot format, for example, 192.168.0.1
dest_ip
Destination IP Port
Type: Integer
Values: 1..65534
dest_port
Cisco D9800 Network Transport Receiver Version 2.75 RESTful Web Services API Reference Guide
198
API Definitions
Output Configuration Command
