URI Parameters (extension to the Command URL separated by /): N/A
All of the URI Arguments below apply to both GET and POST. For GET, the URI arguments do not
need any values, except ‘hdmiindex’ which must be specified. For POST ‘hdmiindex’ must be specified
followed by any of the below URI arguments and the associated value the user would like to set. The
GET result output field names re-use the argument names and possible values.
Note
Table 190: HDMI URI Query/Set Arguments (possible fields and values preceded by ? and separated by &)
DescriptionURI Argument
HDMI Device Instance
Type: Integer
Value: 1..2
hdmiindex (key)
HDMI Color Space
Type: String
Value: "Auto", "YCbCr420", "YCbCr444", "YCbCr422", "RGB"
colorspace
HDMI Color Depth
Type: String
Value: "Auto", "16bit", "12bit", "10bit", "8bit"
colordepth
HDMI Color Range
Type: String
Value: "Auto", "Full", "Limited"
colorrange
HDMI Matrix Coefficients
Type: String
Value: "Auto", "ITU-2020-CL", "ITU-2020-NCL", "ITU-470",
"XvYCC-709", "XvYCC-601", "ITU-709", "SMPTE-170M"
matrixcoeff
HDMI EOTF (Electro-Optical Transfer Function)
Type: String
Value: "Auto", "SMPTE-2084", "HDR", “SDR”
Eotf
HDMI Display Preference
Type: String
Value: "Auto", "SDI1", "SDI2", "HDMI"
displaypref
HDMI Force EDID selector
Type: String
Value: "Yes", "No"
forceedid
Cisco D9800 Network Transport Receiver Version 2.75 RESTful Web Services API Reference Guide
227
API Definitions
Decode Configuration Commands
