A-4

Cisco IOS Software Configuration Guide for Cisco Aironet Access Points

OL-14209-01

Appendix A Protocol Filters

Table 0-3 IP Port Protocols

Protocol Additional Identifier ISO Designator

TCP port service multiplexer tcpmux 1

echo — 7

discard (9) — 9

systat (11) — 11

daytime (13) — 13

netstat (15) — 15

Quote of the Day qotd

quote

Message Send Protocol msp 18

ttytst source chargen 19

FTP Data ftp-data 20

FTP Control (21) ftp 21

Secure Shell (22) ssh 22

Telnet — 23

Simple Mail Transport Protocol SMTP

mail

time timserver 37

Resource Location Protocol RLP 39

IEN 116 Name Server name 42

whois nicname

Domain Name Server DNS

domain

MTP — 57

BOOTP Server — 67

BOOTP Client — 68

TFTP — 69

gopher — 70

rje netrjs 77

finger — 79

Hypertext Transport Protocol HTTP

www

ttylink link 87

Kerberos v5 Kerberos

krb5

supdup — 95

hostname hostnames 101
