Fan exhaust for supervisor and I/O modules5Power supply units (up to 4)—these modules are
a combination of the following:
• 6 kW AC power supply (N7K-AC-6.0KW)
• 7.5 kW AC power supply
(N7K-AC-7.5KW-INT [international
plugs])(N7K-AC-7.5KW-US [US plugs])
• 6 kW DC power supply (N7K-DC-6.0KW)
• Blank filler plate (replaces missing power
supplies to maintain the designed airflow)
2
Handles used to reposition the chassis (do not lift
the chassis with these handles—use a mechanical
lift)
6Fan trays for cooling the supervisor, I/O, and
fabric modules
3
Figure 8: Standard Hardware Features on the Front and Sides of the Cisco Nexus 7018 Chassis, on page 16
and Figure 1-12 show the Cisco Nexus 7018 chassis as it appears when it is fully configured before including
cables for connections to the Internet and the console. The systems that are not fully configured with the
maximum number of supervisor modules, I/O modules, fabric modules, or power supplies have blank panels
installed in place of the missing components to maintain the designed airflow for system cooling.
Note
The I/O module slots hold one or two of the following types of modules:
• F1 Series I/O modules
• 32-port 1- and 10-Gigabit Ethernet I/O modules (N7K-F132XP-15)
• 48-port 1-/10-GBASE-T with XL option (N7K-F248XT-25E)
• F2 Series I/O modules
• 48-port 1-/10-Gigabit SFP+ with XL option and FEX support (N7K-F248XP-25 and
N7K-F248XP-25E
4
)
• F3 Series I/O modules
• 48-port 1-/10-Gigabit Ethernet SFP/SFP+ (N7K-F348XP-25)
• 12-port 40-Gigabit Ethernet QSFP+ (N7K-F312FQ-25)
• 6-port 100-Gigabit Ethernet CPAK (N7K-F306CK-25)
• M1 Series I/O modules
• 48-port 10/100/1000 I/O modules (N7K-M148GT-11)
• 48-port 10/100/1000 I/O modules with XL option (N7K-M148GT-11L)
• 48-port 1-Gigabit Ethernet I/O modules (N7K-M148GS-11)
• 48-port 1-Gigabit Ethernet I/O modules with XL option (N7K-M148GS-11L)
• 32-port 10-Gigabit Ethernet I/O modules with FEX support (N7K-M132XP-12)
• 32-port 10-Gigabit Ethernet I/O modules with XL option and FEX support (N7K-M132XP-12L)
• 8-port 10-Gigabit Ethernet I/O modules with XL option (N7K-M108X2-12L)
4
The Cisco Nexus F2-Series 48-port 1/10-Gigabit SFP+ module supports all of the standard features of F2 modules and it functions like an F2-series module
with Layer 2 and Layer 3 enabled. These modules also support IPv6 DSCP-to-Queue mapping.
