Cisco RV320 User Manual

Setup
Setup Network
Cisco RV320/RV325 Administration Guide 19
3
To configure WAN Connection Settings, select a WAN interface and click Edit.
WAN Connection Settings appears.
Select the WAN Connection Type from the menu and modify the related
parameters as described in these sections:
Obtain an IP Automatically
Choose this option if your ISP dynamically assigns an IP address to the device.
(Most cable modem subscribers use this connection type.) The ISP assigns the
device IP address for this port, including the DNS server IP addresses.
To specify a DNS server, check Use the Following DNS Server Addresses and
enter the IP address of DNS Server 1. Optionally, you can enter a second DNS
server. The first available DNS server is used.
To set the maximum transmission unit (MTU) size automatically, select Auto.
Otherwise, to set the MTU size manually, select Manual and enter the MTU size.
(The size in bytes of the largest protocol data unit that the layer can pass.)
To configure the IPv6 parameters, check Enable. The DHCPv6 client process and
requests for prefix delegation through the selected interface are enabled. Use this
option when your ISP is capable of sending LAN prefixes by using DHCPv6. If your
ISP does not support this option, manually configure a LAN prefix:
NOTE When DHCP-PD is enabled, manual LAN IPv6 addressing is disabled. When DHCP-
PD is disabled, manual LAN IPv6 addressing is enabled.
• LAN IPv6 Address—Global IPv6 prefix that was assigned by your ISP for
your LAN devices, if applicable. (Check with your ISP for more information.)
• Prefix Length—IPv6 prefix length: The IPv6 network (subnet) is identified
by the initial bits of the address called the prefix. All hosts in the network
have the identical initial bits for their IPv6 address. Enter the number of
common initial bits in the network addresses. The default prefix length is 64.
• LAN Prefix Assignment:
- Without any action—Does not provide Stateless or Stateful IPv6
address for LAN-side PCs.
- Configure to RA automatically—Provides Stateless IPv6 address for
LAN-side PCs.
- Configure to DHCPv6 automatically—Provides Stateful IPv6 address
for LAN-side PCs.

Cisco RV320 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB version	2.0
USB ports quantity	2
Ethernet LAN (RJ-45) ports	6
Gigabit Ethernet (copper) ports quantity	4
Routing protocols	RIP-1, RIP-2
Supported network protocols	IPv4, IPv6, Static IP, PPPoE, PPTP, DNS, DynDNS
VPN support	IPsec, L2TP, DPD, DNS
Firewall security	Port Address Translation (PAT) firewall, Stateful packet inspection (SPI) firewall, Network address translation (NAT) firewall
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, HTTPS, MD5, SHA-1, SSL/TLS
VPN tunnels quantity	25
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC, CE, UL, cUL, CB, CCC, BSMI, KC, Anatel
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No
LED indicators	Activity, LAN, Link, Power, USB, WAN
Input current	1.5 A
Output voltage	12 V

Weight and Dimensions

Depth	44 mm
Width	206 mm
Height	132 mm
Weight	- g
