Cisco RV320 User Manual

Setup
Setup Network
24 Cisco RV320/RV325 Administration Guide
3
Stateless Address Autoconfiguration (IPv6)
Choose this option if your ISP uses IPv6 Router Solicitations and Router
Advertisements, hosts on the network learn which network they are connected to,
and once they do, they can automatically configure a host ID on that network.
To specify a DNS server, enter the IP address of DNS Server 1. Optionally, you can
enter a second DNS server. The first available DNS server is used.
To set the maximum transmission unit (MTU) size automatically, select Auto.
Otherwise, to set the MTU size manually, select Manual and enter the MTU size.
(The size in bytes of the largest protocol data unit that the layer can pass.)
To configure the IPv6 parameters:
• LAN IPv6 Address—Global IPv6 prefix that was assigned by your ISP for
your LAN devices, if applicable. (Check with your ISP for more information.)
• Prefix Length—IPv6 prefix length: The IPv6 network (subnet) is identified
by the initial bits of the address called the prefix. All hosts in the network
have the identical initial bits for their IPv6 address. Enter the number of
common initial bits in the network addresses. The default prefix length is 64.
• LAN Prefix Assignment:
- Without any action—Does not provide Stateless or Stateful IPv6
address for LAN-side PCs.
- Configure to RA automatically—Provides Stateless IPv6 address for
LAN-side PCs.
- Configure to DHCPv6 automatically—Provides Stateful IPv6 address
for LAN-side PCs.
- Configure to RA and DHCPv6 automatically—Provides Stateless and
Stateful IPv6 addresses for LAN-side PCs.

Cisco RV320 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB version	2.0
USB ports quantity	2
Ethernet LAN (RJ-45) ports	6
Gigabit Ethernet (copper) ports quantity	4
Routing protocols	RIP-1, RIP-2
Supported network protocols	IPv4, IPv6, Static IP, PPPoE, PPTP, DNS, DynDNS
VPN support	IPsec, L2TP, DPD, DNS
Firewall security	Port Address Translation (PAT) firewall, Stateful packet inspection (SPI) firewall, Network address translation (NAT) firewall
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, HTTPS, MD5, SHA-1, SSL/TLS
VPN tunnels quantity	25
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC, CE, UL, cUL, CB, CCC, BSMI, KC, Anatel
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No
LED indicators	Activity, LAN, Link, Power, USB, WAN
Input current	1.5 A
Output voltage	12 V

Weight and Dimensions

Depth	44 mm
Width	206 mm
Height	132 mm
Weight	- g
