Cisco RV320 User Manual

VPN
Client to Gateway
92 Cisco RV320/RV325 Administration Guide
8
- Version 4.9 supports Mac OS X 10.4 and 10.5
- Version 4.8 supports Intel based Linux
To set it up Easy VPN, configure a group password on this page, and add a
username and password for each Cisco VPN Client users in the User
Management Table in the User Management section. When adding a user,
the Unassigned group should be selected. The other groups are used for
SSL VPN.
Configure Tunnel or Group VPN
Enter the following information:
• Tunnel Name—Name to describe the tunnel. For a single user, you can enter
the username or location. For a group VPN, you could identify the group
business role or location. This description is for your reference and does not
have to match the name used at the other end of the tunnel.
• Interface—WAN port.
• Keying Mode—Choose the key management method:
- Manual—Generate the key yourself, but do not enable key negotiation.
Manual key management is used in small static environments or for
troubleshooting purposes. Enter the required settings.
- IKE (Internet Key Exchange) with Preshared Key—Use this protocol to
set up a Security Association (SA) for your tunnel. (This setting is
recommended.) If you selected Group VPN, this is the only option
available.
- IKE with Certificate—Use a certificate to authenticate a remote IKE
peer.
• Enable—Check to enable this VPN.
Configuring Easy VPN
Enter the following information:
• Name—Name to describe the tunnel. For a single user, you can enter the
username or location. This description is for your reference and does not
have to match the name used at the other end of the tunnel.
• Minimum Password Complexity—When enabled, the password minimum
requirements are:
- Eight characters in length.

Cisco RV320 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB version	2.0
USB ports quantity	2
Ethernet LAN (RJ-45) ports	6
Gigabit Ethernet (copper) ports quantity	4
Routing protocols	RIP-1, RIP-2
Supported network protocols	IPv4, IPv6, Static IP, PPPoE, PPTP, DNS, DynDNS
VPN support	IPsec, L2TP, DPD, DNS
Firewall security	Port Address Translation (PAT) firewall, Stateful packet inspection (SPI) firewall, Network address translation (NAT) firewall
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, HTTPS, MD5, SHA-1, SSL/TLS
VPN tunnels quantity	25
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC, CE, UL, cUL, CB, CCC, BSMI, KC, Anatel
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No
LED indicators	Activity, LAN, Link, Power, USB, WAN
Input current	1.5 A
Output voltage	12 V

Weight and Dimensions

Depth	44 mm
Width	206 mm
Height	132 mm
Weight	- g
