Cisco RV320 User Manual

VPN
Client to Gateway
Cisco RV320/RV325 Administration Guide 93
8
- Not match the the username.
- Not match the current password.
- Contain characters from at least 3 of the following categories:
uppercase letters, lowercase letters, numbers, special characters
available on the standard keyboard (' ' " \ are not supported).
• Password—Easy VPN password.
• Password Strength Meter—When Minimum Password Complexity is
enabled, the Password Strength Meter indicates the password strength,
based on the complexity rules. The scale ranges from red (unacceptable) to
yellow (acceptable) to green (strong).
• Interface—WAN port to use for this tunnel.
• Enable—Check this box to enable the VPN tunnel, or uncheck it to disable
the tunnel. By default, the tunnel is enabled.
• Tunnel Mode—Split Tunneling allows Internet destined traffic to be sent
unencrypted directly to the Internet. Full Tunneling sends all traffic to the
head-end device where it is then routed to destination resources
(eliminating the corporate network from the path for Web access).
• IP Address—IP address assigned to the VPN interface.
• Subnet Mask—Subnetwork mask.
• Extended Authentication—Uses an IPsec host username and password to
authenticate the VPN clients or it uses the user database found in User
Management. To use the IPsec Host, click the radio button and enter the
User Name and Password. To use the Edge Device, click the radio button
and select the database from the drop-down menu. To add or edit the
database, click Add/Edit to display the User Management window.

Cisco RV320 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB version	2.0
USB ports quantity	2
Ethernet LAN (RJ-45) ports	6
Gigabit Ethernet (copper) ports quantity	4
Routing protocols	RIP-1, RIP-2
Supported network protocols	IPv4, IPv6, Static IP, PPPoE, PPTP, DNS, DynDNS
VPN support	IPsec, L2TP, DPD, DNS
Firewall security	Port Address Translation (PAT) firewall, Stateful packet inspection (SPI) firewall, Network address translation (NAT) firewall
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, HTTPS, MD5, SHA-1, SSL/TLS
VPN tunnels quantity	25
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC, CE, UL, cUL, CB, CCC, BSMI, KC, Anatel
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No
LED indicators	Activity, LAN, Link, Power, USB, WAN
Input current	1.5 A
Output voltage	12 V

Weight and Dimensions

Depth	44 mm
Width	206 mm
Height	132 mm
Weight	- g
