Administration: Diagnostics
Configuring Port and VLAN Mirroring
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 79
7
STEP 6 If Local VLAN Based is selected, enter the following information:
• Destination Port—Select the analyzer port to where packets are copied.
• Allow Ingress Packets—Check Enable to allow the destination port to send
or receive normal packets.
• VLAN—Select the source VLAN from where traffic is mirrored.
STEP 7 If RSPAN Source Session is selected, enter the following information:
• RSPAN VLAN—Select the VLAN to be used to copy traffic to another
device. This VLAN should be same as the VLAN defined in the RSPAN VLAN
ID field.
• Reflector Port—Select the port or LAG to be connected to another device.
• Source Type—Select Port or VLAN as the source port or source VLAN.
If Port is selected, select the source ports from where traffic is mirrored and
select the type of traffic to be mirrored to the analyzer port. The options are:
- Rx Only—Port mirroring on incoming packets.
- Tx Only—Port mirroring on outgoing packets.
- Tx and Rx—Port mirroring on both incoming and outgoing packets.
- N/A—Traffic from this port is not mirrored.
If VLAN is selected, select a source VLAN from where traffic is mirrored.
- VLAN—Select a VLAN as the source VLAN.
STEP 8 If RSPAN Destination Session is selected, enter the following information:
• RSPAN VLAN—Select a VLAN to be used to copy traffic to another device.
This VLAN should be same as the VLAN defined in the RSPAN VLAN ID field.
• Destination Port—Select the analyzer port to where packets are copied.
• Allow Ingress Packets—Check Enable to allow the destination port to send
or receive normal packets.
STEP 9 Click Apply. The Running Configuration is updated.
