ARES 506-606 - 02.2005 - GB
G.2
CHARACTERISTICS
LINKAGE
Linkage lift capability at the swivel joints throughout its range: 6550 daN.
HYDRAULIC SYSTEM
- Closed centre circuit flow LS in l/min: 100 or 110; (Except 546: 100 or 90)
- Open centre circuit flow un l/min: 60;
- Pressure in bar: 200;
- Capacity in litres of the gearbox sump and rear axle: 65;
- Minimum/maximum difference in litres: 8;
- Volume of oil in litres that can be taken for static constraints: 15.
HITCH
Linkage: Electronic Tracto-Control
TCE 15 TCE 25 TCE 15T
Functions
Position display Yes Yes Control knob position
Force control Automatic Automatic Automatic
Mixed control Yes Yes Yes
Travelling damper Yes Yes Yes
Upper limit adjustment Yes Yes Yes
Sensitivity adjustment Yes Yes Yes
Rate of descent adjustment Yes Yes Yes
Lifting/lowering control Yes Yes Yes
Control to interrupt arm movement Yes Yes Yes
Quick soil entry control Yes Yes Yes
External step by step controls Yes Yes Yes
Wheel slip control No Yes No
Degree of wheel slip display No Yes No
Maximum static load Vertical
Trailer hitch yoke 1800 daN
Hitch stud 2500 daN
Oscillating bar
1700 daN (bar out)
2400 daN (bar retracted)
Picker hook 3000 daN
