ARES 506-606 - 02.2005 - GB
G.15
AUXILIARY SPOOL VALVES
Matching power take-offs with indications:
Indication 1 for power-take-offs (1).
Indication 2 for power-take-offs (2).
Indication 3 for power-take-offs (3).
Indication 4 for power-take-offs (4).
Indication 5 for power take-offs (5), (A) and (B).
Note: Power take-off (5A) or (3) and (5B) or (4) are mounted
in parallel with power take-offs (5A) and (5B), at the front of
the tractor. These side connectors function with the
electropilot or the cross lever.
394msn02
394msn03
395msn01
395msn02
4
3
2
1
1234
12
5
1
2
5
A
B
5
5
BA
