CleaverBrooks CBT User Manual

750-382
CBT
4-13
Full modulation boilers
Annunciation
Configuration
Annunciator 6 long
name
OEM LOW GAS
PRESSURE
374
Annunciation
Configuration
Annunciator 7
location
Service E:Other
annunciation
384
Annunciation
Configuration
Annunciator7 short
name
Service A7 385
Annunciation
Configuration
Annunciator 7 long
name
Service Annunciator7 387
Annunciation
Configuration
Annunciator 8
location
Service E:Other
annunciation
397
Annunciation
Configuration
Annunciator8 short
name
Service A8 398
Annunciation
Configuration
Annunciator 8 long
name
Service Annunciator8 400
Annunciation
Configuration
PII short name OEM PII 410
Annunciation
Configuration
PII long name OEM Pre-Ignition ILK 412
Annunciation
Configuration
LCI short name OEM LCI 422
Annunciation
Configuration
LCI long name OEM Limit Circuit Input 424
Annunciation
Configuration
ILK short name OEM ILK 434
Annunciation
Configuration
ILK long name OEM Interlock 436
Burner Control
Interlocks
Purge rate proving OEM Fan speed 229
Burner Control
Interlocks
Lightoff rate proving Service Fan speed except
during ignition
230
Burner Control
Interlocks
Interlock open
response
Read Only Lockout 238
Burner Control
Interlocks
Interrupted air switch
enable
Service Enable IAS during
purge & ignition
246
Burner Control
Interlocks
LCI enable Read Only Enabled 248
Burner Control
Interlocks
PII enable Service Disabled 249
Burner Control
Interlocks
ILK bounce detection
enable
OEM Enabled 253
Burner Control
Timings & Rates
Prepurge rate OEM 3000rp
m
4000rpm 6500rpm RPM 196
Burner Control
Timings & Rates
Postpurge rate Service 1000rp
m
2000rpm 6500rpm RPM 198
Burner Control
Timings & Rates
Standby rate Service 0rpm 0rpm 3000rpm RPM 207
Burner Control
Timings & Rates
Prepurge time Service 0m 30s 0m 30s 15m 0s mmm ss 231
Burner Control
Timings & Rates
Run stabilization time Service 0m 10s 15m 0s mmm ss 235
Burner Control
Timings & Rates
Postpurge time Service 0m 15s 0m 15s 15m 0s mmm ss 236
Burner Control
Timings & Rates
Forced recycle
interval time
OEM 0h 0m min 254
Burner Control
Ignition
Pilot test hold Service Off 197
TABLE 4- 1.
CB Falcon factory parameter settings - Model CBT-M (Continued)
Parameter Group Parameter Name Access Min.
Range
Default Setting Max.
Range
Parameter Units Installation
Setting
Modbus
Register
(dec)
