CleaverBrooks CBT User Manual

Commissioning
4-14
750-382
CBT
Burner Control
Ignition
Lightoff rate Service 1000rp
m
2000rpm 3000rpm RPM 197
Burner Control
Ignition
Preignition time Service 0m 0s 15m 0s mmm ss 232
Burner Control
Ignition
PFEP Read Only 4 seconds 233
Burner Control
Ignition
Flame threshold OEM 0.5 0.8 5 10ths (V or uA) 250
Burner Control Flame
Failure
Ignite failure response Service Lockout 239
Burner Control Flame
Failure
Ignite failure retries OEM 1 240
Burner Control Flame
Failure
Ignite failure delay Service 0m 0s mmm ss 241
Burner Control Flame
Failure
Run flame failure
response
Read Only Lockout 243
Burner Control Flame
Failure
Fan speed error
response
OEM Lockout 255
System Configuration Burner Enable User No//Off 203
System Configuration Flame sensor type Service UV power tube with
spark interference
228
System Configuration Modulation output OEM Fan PWM 192
System Configuration Temperature units Service A:Fahrenheit 178
System Configuration Antishort cycle time Service 0m 0s mmm ss 179
System Configuration Alarm silence time Service mmm ss
System Configuration Line frequency Service Auto detect 48
through 63 Hz
630
System Configuration Safety configuration
options
OEM Ignore Flame rod
faults for UV config
631
Sensor Configuration S1 (J8-4) sensor type Service 0-150 psi 608
Sensor Configuration S2 (J8-6) sensor type Service Unconfigured 609
Fan Configuration Absolute max fan
speed
OEM 2000 6500 6500 RPM 256
Fan Configuration Absolute min fan
speed
OEM 800 900 3000 RPM 257
Fan Configuration PWM frequency OEM D:3000 Hz 258
Fan Configuration Pulses per revolution Read Only 2 3 3 259
Fan Configuration Fan speed up ramp Service 0 0 1000 RPM/sec 260
Fan Configuration Fan slow down ramp Service 0 0 1000 RPM/sec 261
Fan Configuration Fan gain up Service 30 262
Fan Configuration Fan gain down Service 30 263
Fan Configuration Fan min duty cycle Service 10 0-100% 264
Lead Lag Master
Configuration
Lead lag master
enable
Service No Lead Lag master 545
Lead Lag Master
Configuration
Lead lag hysteresis
step time
Service 0m 0s mmm ss 551
Lead Lag Master
Configuration
Lead lag P gain Service 10 552
Lead Lag Master
Configuration
Lead lag I gain Service 10 553
TABLE 4- 1.
CB Falcon factory parameter settings - Model CBT-M (Continued)
Parameter Group Parameter Name Access Min.
Range
Default Setting Max.
Range
Parameter Units Installation
Setting
Modbus
Register
(dec)
