CleaverBrooks CBT User Manual

750-382
CBT
4-15
Full modulation boilers
Lead Lag Master
Configuration
Lead lag D gain Service 0 554
Lead Lag Master
Configuration
Lead lag operation
switch
Service No//Off 555
Lead Lag Master
Configuration
Lead lag Steam
demand switch
Service STAT terminal 556
Lead Lag Master
Configuration
Lead lag Steam
setpoint source
OEM Local setpoint is
used
557
Lead Lag Master
Configuration
Lead lag modulation
sensor
Service S2 (J8-6) Steam
sensor
558
Lead Lag Master
Configuration
Lead Lag Modbus
port
OEM MB2 569
Lead Lag Master
Configuration
Base load common Service 75% 0 to 100% 572
Lead Lag Master
Configuration
Lead selection
method
Service Sequence order 574
Lead Lag Master
Configuration
Lag selection method Service Sequence order 575
Lead Lag Master
Configuration
Lead lag add stage
method 1
Service Firing rate threshold
to add stage
714
Lead Lag Master
Configuration
Lead lag add stage
detection time 1
Service 2m 0s mmm ss 716
Lead Lag Master
Configuration
Lead lag add stage
rate offset
Service 0% -100% to 100% 719
Lead Lag Master
Configuration
Lead lag add stage
interstage delay
Service 3m 0s mmm ss 722
Lead Lag Master
Configuration
Lead lag drop stage
method 1
Service Firing rate to drop
stage
723
Lead Lag Master
Configuration
Lead lag drop stage
detection time 1
Service 1m 0s mmm ss 725
Lead Lag Master
Configuration
Lead lag drop stage
rate offset
Service -3% -100% to 100% 728
Lead Lag Master
Configuration
Lead lag drop stage
interstage delay
Service 3m 0s mmm ss 731
Lead Lag Master
Configuration
Lead rotation time Service 120h 0m min 733
Lead Lag Master
Configuration
Force lead rotation
time
Service 168h 0m min 734
Lead Lag Master
Configuration
Lead lag pressure
setpoint
User 0 10 135 psig 738
Lead Lag Master
Configuration
Lead lag pressure
TOD setpoint
Service 0 psig 739
Lead Lag Master
Configuration
Lead lag pressure on
hysteresis
Service 0 psig 740
Lead Lag Master
Configuration
Lead lag pressure off
hysteresis
Service 6 psig 741
Lead Lag Master
Configuration
Lead lag add stage
pressure error
threshold
Service 3 psig 742
Lead Lag Master
Configuration
Lead lag drop stage
pressure error
threshold
Service 3 psig 743
Lead Lag Master
Configuration
Lead lag 4 mA steam
pressure
Service 0 0 psig 745
Lead Lag Master
Configuration
Lead lag 20 mA
steam pressure
Service 0 135 150 psig 746
Lead Lag Slave
Configuration
Lead lag slave enable Service Disabled 544
TABLE 4- 1.
CB Falcon factory parameter settings - Model CBT-M (Continued)
Parameter Group Parameter Name Access Min.
Range
Default Setting Max.
Range
Parameter Units Installation
Setting
Modbus
Register
(dec)
