Figure 1-8 CFC Heat Flow and Component Orientation
Combustion Fan and
Premix Gas Valve
Assembly
Control
Panel
“Finned” High
Efficiency AluFer
Tubes
Flue Gas
Outlet
Low Temp.
Return
Hot Water
Outlet
Safety Relief Valve
Insulation Blanket
Ignition Electrodes
Flame Rod
Burner
Canister
High Temp.
Return
and
