APPENDIX B: HYDRONIC DEVICE PARAMETER WORKSHEET EXAMPLE
Table 48. Example of a Completed Device Parameter Worksheet.
Parameter Name
Customer
Choice - Hidden,
Read Only or
Password
protected Minimum Range Default Setting Maximum Range Parameter Units
Burner cycle count Read Only 0 Cycles
Burner run time Read Only 0 Hours
CH pump cycles Read Only 0 Cycles
DHW pump cycles Read Only 0 Cycles
System pump cycles Read Only 0 Cycles
Boiler pump cycles Read Only 0 Cycles
Auxiliary pump cycles Read Only 0 Cycles
Temperature units Read Only A:Fahrenheit
Antishort cycle time Read Only 1m 0s mmm:ss
Alarm silence time Read Only 5m 0s mmm:ss
Burner name Read Only 20 chars
Installation data Read Only 20 chars
OEM identification Read Only 20 chars
Modulation output Hidden B:Demand rate is
in % units
CH maximum modulation
rate
Read Only 100% % | RPM
DHW maximum modulation
rate
Read Only 100% % | RPM
Minimum modulation rate Read Only 0% % | RPM
Prepurge rate Read Only 100% % | RPM
Lightoff rate Read Only 25% % | RPM
Postpurge rate Read Only 25% % | RPM
CH forced rate Read Only 25% % | RPM
CH forced rate time Read Only 1m 0s mmm:ss
DHW forced rate Read Only 25% % | RPM
DHW forced rate time Read Only 120m 0s mmm:ss
Burner switch Read Only Yes/True/On
Firing rate control Read Only A:Automatic firing
Manual firing rate Read Only 25% % | RPM
Analog output hysteresis Read Only 0 20 1 to 10
CH enable Read Only Enabled
CH demand source Read Only D:Sensor & LCI
CH sensor Read Only A:Outlet sensor
CH setpoint Read Only 32°F 0°C 180°F 82°C 240°F 116°C
CH tod setpoint Read Only 32°F 0°C 160°F 71°C 240°F 116°C
CH on hysteresis Read Only 2°F 1°C 15°F 8°C 100°F 56°C
CH off hysteresis Read Only 2°F 1°C 15°F 8°C 100°F 56°C
CH outdoor reset enable Read Only Disabled
