CB FALCON
101 750-265
CH P gain Read Only 50 400
CH I gain Read Only 50 400
CH D gain Read Only 0 400
CH hysteresis step time Read Only 1m 0s mmm:ss
Ignition source Read Only A:Internal ignition
(spark)
BLR HSI function Read Only A:Blower motor
Igniter on during Read Only A:On throughout
PFEP
Pilot type Read Only A:Interrupted (off
during Run)
Flame sensor type Read Only A:No flame sensor
Purge rate proving Read Only B:Prove via HFS
terminal
Lightoff rate proving Read Only B:Prove via LFS
terminal
Prepurge time Read Only 0m 30s mmm:ss
Preignition time Read Only 0m 0s mmm:ss
PFEP Read Only C:10 seconds
MFEP Read Only C:10 seconds
Run stabilization time Read Only 0m 10s mmm:ss
Postpurge time Read Only 0m 15s mmm:ss
Interlock start check enable Read Only Disabled
Interlock open response Read Only A:Lockout
Ignite failure response Read Only A:Lockout
Ignite failure retries Read Only A:Number of
retries not set
Ignite failure delay Read Only 5m 0s mmm:ss
MFEP flame failure response Read Only A:Lockout
Run flame failure response Read Only A:Lockout
Pilot test hold Hidden Disabled
NTC sensor type Read Only A:10K dual safety
Interrupted air switch enable Read Only A:no IAS
IAS start check enable Hidden Enabled
LCI enable Read Only Enabled
PII enable Read Only Enabled
Flame threshold Read Only 2 8 140 .1 Volts/uA
Absolute max fan speed Read Only 500 5000 7000 RPM
Absolute min fan speed Read Only 500 800 5000 RPM
PWM frequency Read Only D:3000 Hz
Pulses per revolution Read Only 1 3 10
Fan speed up ramp Read Only 0 RPM/sec
Fan slow down ramp Read Only 0 RPM/sec
Fan gain up Read Only 50 100
Fan gain down Read Only 50 100
Table 48. Example of a Completed Device Parameter Worksheet. (Continued)
Parameter Name
Customer
Choice - Hidden,
Read Only or
Password
protected Minimum Range Default Setting Maximum Range Parameter Units
