CleaverBrooks CFC-1000 User Manual

Section 2 — Installation
Part No. 750-263 2-25
Figure 2-29 Pressure Drop Curve, CFC 1000, U.S. Flow Rates
Figure 2-30 Pressure Drop Curve, CFC 1000, Metric Flow Rates
Hydraulic Resistance CFC 1000
0
0.2
0.4
0.6
0.8
1
1.2
0 8.8 22 44 66 88 110 132 154 176
Flow - GPM
Pressure - PSI
Hydraulic Resistance CFC 1000
0
10
20
30
40
50
60
70
80
0 2 5 10152025303540
Flow m3/h
Pressure mbar
