ChargeIndicatorLight
ELECTRICALCOMPONENTS:ELECTRIC
VEHICLE
2
1
1
3
4
9
6
8
702
Figure13-1InstrumentPanelRemoval
703
Figure13-2KeySwitch
CHARGEINDICATORLIGHT
SeeGeneralWarningsonpage1-2.
TESTINGTHECHARGEINDICATORLIGHT
SeeTestProcedure17–ChargeIndicatorLightonpage12-38.
CHARGEINDICATORLIGHTREMOVAL
1.Disconnectthebatteriesanddischargethecontroller.SeeDisconnectingtheBatteries–ElectricVehicles
onpage1-4.
2.Removeinstrumentpanel.SeeKeySwitchRemovalonpage13-1.
3.Disconnectthewiresatthewarninglight.
4.Pressthetworetainingtabs(1)andremovethelightfromthecenterdash(Figure13-3,Page13-3).
CHARGEINDICATORLIGHTINSTALLATION
1.Installinreverseorderofremoval.
2.PlacetheTow/RunswitchintheTOWpositionandconnectthebatteries.SeeConnectingtheBatteries–
ElectricVehiclesonpage1-4.
Page13-22018OnwardMaintenanceandServiceManual
