Club Car Onward 2018 Service Manual

ELECTRICALCOMPONENTS:ELECTRIC
VEHICLEElectronicsModule
13
2
3
1
8
11
4
6
5
7
10
9
2771
Figure13-11ControllerandSolenoidRemoval
ELECTRONICSMODULEINSTALLATION
1.Returnelectronicsmodule(3)toitslocationinvehiclebutleaveittiltedforward.
2.Completeconnectionstothecontroller(1),theTow/Runswitch(5)andthesolenoid(4)pertheelectrical
schematics.SeeWiringDiagramsonpage12-4.
3.Tightenbolts(6)onthecontrollerto108lb·in(12.2N·m).
4.Tightennuts(7)onthesolenoidto6.4lb·ft(8.7N·m).
2018OnwardMaintenanceandServiceManualPage13-11
